Frame
Moterra Carbon Front Triangle, SmartForm C1 Alloy Swingarm, 150mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH hanger, post mount brake, 1.5” – 1.8” tapered headtube, 18mm two-bolt kickstand mount
-
Fork
RockShox Lyrik Select, 150mm, DebonAir, 15x110mm thru-axle, tapered steered, 44mm offset
-
Headset
Acros integrated sealed bearing, tapered
-
Rear Shock
RockShox Deluxe Select+, DebonAir, 2-Pos mode adjust, adjustable rebound
-
Drive Unit
Bosch Performance Line CX 250W
-
Battery
Bosch PowerTube, 750Wh
-
Charger
Bosch 4A
-
Display
Bosch Kiox 300 w/ LED remote
-
Certifications
UL 2849
-
Rear Derailleur
Shimano XT
-
Shifters
Shimano SLX, 12-speed
-
Chain
Shimano SLX, 12-speed
-
Crank
FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T
-
Rear Cogs
Shimano SLX, 10-51, 12-speed
-
Brakes
Shimano MT520 4-piston hydraulic disk, 203/203mm RT64 rotors
-
Brake Levers
Shimano MT501 hydraulic disk
-
Rims
WTB ST i30 TCS, 32h, tubeless ready
-
Spokes
DT Swiss Champion
-
Tire Size
2.6
-
Wheel Size
29
-
Hubs
(F) Formula 15x110mm thru-axle / (R) Shimano MT410, 12x148mm thru-axle
-
Tires
(F) Maxxis Minion DHF, 29x2.6", EXO, tubeless ready / (R) Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready
-
Front Tire
Maxxis Minion DHF, 29x2.6", EXO, tubeless ready
-
Rear Tire
Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready
-
Handlebar
Cannondale 3 Riser, 6061 Alloy, 25mm rise, 8° sweep, 5° rise, 800mm
-
Stem
Cannondale 2, 6061 Alloy, 35mm, 0°
-
Grips
Fabric FunGuy
-
Saddle
Fabric Scoop Shallow Sport, steel rails
-
Seatpost
Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M), 170mm (L-XL)
-
Extra
Pre-installed light cable. (Note: this model is not compatible with Bosch Range Extender)
